8-19
Duralink64 Port Aggregation for Windows NT
Viewing the Groups
You can view the groups list in two ways:
■ To view ports in a specific group, click the PLUS SIGN [+] .
■ To hide ports in a specific group, click the MINUS SIGN [-] .
■ Disabled ports are marked with an [x], such as ADPTSF5 shown
below.
Figure 8-17. Example of disabled ports
f Speed Speed is either 10 or 100. This value depends on the
connection type you chose in Configuring the Ports on
page 8-2.
g Duplexity Duplexity is either half or full. This value depends
on the connection type you chose in Configuring the
Ports on page 8-2.
h Group
Transmit
Total
This field appears only when a group is selected.
