34
(GB)
;;;;;;;;
;;;;;;;;
;;;;;;;;
;;;;;;;;
;;;;;;;;
a
x
b
c
PUSH
PUSH
+ 0 –
a: Distance between the screen and the center
of the lens
b: Distance from the floor to the center of the
lens
c: Distance from the floor to the foot of the
projector
x: Free
Center of the lens
Center of the screen
Wall
Floor
Distance between the front of the
cabinet and the center of the lens
Standard lens:
–25.4 mm (–1 inch)
Installation Example
Installation Example
SS 40 60 80 100 120 150 180 200 250 300
Minimum
1458 2217 2977 3736 4495 5635 6774 7533 9432 11330
a
(57 1 /
2
) (87 1 /
2
) (117 3 /
8
) (147 3 /
8
) (177 1 /
4
) (221 3 /
4
) (266 5 /
8
) (296 1 /
2
) (371 3 /
8
) (446 1 /
8
)
Maximum
1764 2675 3586 4497 5408 6774 8141 9052 11329 13607
(69 3 /
8
) (105 1 /
4
) (141 3 /
8
) (177 1 /
4
) (213 1 /
8
) (266 5 /
8
) (320 5 /
8
) (356 3 /
8
) (446 1 /
8
) (536)
b
x–305 x–457 x–610 x–762 x–914 x–1143 x–1372 x–1524 x–1905 x–2286
(x–12) (x–18) (x–24) (x–30) (x–36) (x–45) (x–54) (x–60) (x–75 1 /
8
) (x–90 1 /
8
)
c
x–388 x–541 x–693 x–845 x–998 x–1226 x–1455 x–1607 x–1988 x–2369
(x–15 3 /
8
) (x–21 3 /
8
) (x–27 3 /
8
) (x–33 3 /
8
) (x–39 3 /
8
) (x–48 3 /
8
) (x–57 3 /
8
) (x–63 3 /
8
) (x–78 3 /
8
) (x–93 3 /
8
)
Unit: mm (inches)
To calculate the installation measurements (unit: mm)
SS: screen size diagonal (inches)
a (minimum) = {(SS
Ч 33.60/0.9071) – 59.7012} Ч 1.025
a (maximum) = {(SS Ч 42.376846/0.9071) – 59.62151} Ч 0.975
b = x – (SS/0.9071
× 6.912)
c = x – (SS/0.9071
× 6.912 + 83.4)
VPL-PX15/PX10
SS 40 60 80 100 120 150 180 200 250 300
Minimum
1461 2221 2982 3742 4503 5644 6784 7545 9446 11348
a
(57 1 / 2 ) (87 1 / 2 ) (117 3 / 8 ) (147 3 / 8 ) (177 1 / 4 ) (222 1 / 8 ) (267) (297 3 / 8 ) (372 1 / 8 ) (447)
Maximum
1767 2680 3592 4505 5417 6786 8154 9067 11348 13629
(69 3 / 4 ) (105 5 / 8 ) (141 3 / 8 ) (177 1 / 4 ) (213 1 / 2 ) (267 3 / 8 ) (321) (357 1 / 4 ) (447) (536 3 / 4 )
b
x–305 x–458 x–611 x–763 x–916 x–1145 x–1374 x–1527 x–1908 x–2290
(x–12 1 / 8 ) (x–18 1 / 8 ) (x–24 1 / 8 ) (x–30 1 / 8 ) (x–36 1 / 8 ) (x–45 1 / 8 ) (x–54 1 / 8 ) (x–60 1 / 8 ) (x–75 1 / 4 ) (x–90 1 / 4 )
c
x–389 x–541 x–694 x–847 x–999 x–1228 x–1457 x–1610 x–1992 x–2373
(x–15 3 /
8
) (x–21 3 /
8
) (x–27 3 /
8
) (x–33 3 /
8
) (x–39 3 /
8
) (x–48 3 /
8
) (x–57 3 /
8
) (x–63 1 /
2
) (x–78 1 /
2
) (x–93 1 /
2
)
Unit: mm (inches)
To calculate the installation measurements (unit: mm)
SS: screen size diagonal (inches)
a (minimum) = {(SS
Ч 33.59/0.9055) –59} Ч 1.025
a (maximum) = {(SS Ч 42.370377/0.9055) – 58.9761} Ч 0.975
b = x – (SS/0.9055
× 6.912)
c = x – (SS/0.9055
× 6.912 + 83.4)
VPL-PS10
