27
Keyboard Installation and Operation
Telemetry Enable/Disable (RS485 only)
To send telemetry commands to cameras, it is necessary to enable telemetry to the selected
camera. The telemetry key has a toggle action.
To enable/disable telemetry:
1.
Press the TELEMETRY (
) key. Pressing the key again will disable telemetry.
Note it is not necessary to enable telemetry in order to use the joystick to control the
movement of a camera.
Initiating F1 Key Commands (RS232 only)
The F1 key on the keyboard is a special function key which, when used with numeric
keyboard inputs, accomplish special functions within a matrix system. Refer to the matrix
documentation for a listing of supported commands.
To perform an F1 function key command:
1.
Enter the number for the command using the numeric keys.
2.
Press the F1 (
) key.
