Slide-in the battery into its compartment. Switch-on the
WZE-3 using the blue „on/off“ button.
The unit tries to connect to a corresponding radio unit.
If ok, both the „ready“ and „RF-active“ LEDs glow green
after a few moments. If not, check the following table:
14
LED signal description solution
rdy green RF connection disturbed or interrupted remove other radio controlled devices from the set,
RF red change radio channel from odd to even numbers or vice versa
rdy red Radio connection ok, but no or bad check connectors on WZE-3 and ZMU-3
RF green connection to ZMU-3
rdy red no radio connection check, if the corrsponding radio unit is active*
RF dark check radio units for corresponding channels
replace antenna on corresponding radio units*+
* UMC-3, URM-2/-3, ARRIFLEX 416 PLUS(HS).
+The antenna on the WZE-3 is not user replacable
Operation of the WZE
-3
5. Operation of the WZE-3
