Atwood Mobile Products HYDRO FLAME 2540 - Manual

1
WARNING: If the information in this manual is
not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of
life.
—
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Evacuate all persons from vehicle.
• Shut off gas supply at gas container or source.
• Do not touch any electrical switch, or use any
phone or radio in vehicle.
• Do not start vehicle’s engine or electric generator.
• Contact nearest gas supplier or qualified Service
Technician for repairs.
• If you cannot reach a gas supplier or qualified
Service Technician, contact the nearest fire
department.
• Do not turn on gas supply until gas leak(s) has
been repaired.
— Installation and service must be performed by a
qualified Service Technician, Service Center or
gas supplier.
THIS INSTRUCTION MANUAL IS FOR USE BY AN AUTHORIZED SERVICE
TECHNICIAN TO INSTALL AN ATWOOD
- hydro flame
TM FURNACE .
INSTALLER
:
LEAVE THIS MANUAL WITH APPLIANCE
.
CONSUMER
:
RETAIN THIS MANUAL FOR FURTHER REF
-
ERENCE
.
This furnace design has been certified for installation in recre-
ation vehicles as a MSP Category III furnace. Follow this
installation instruction to insure safe operation of the furnace.
Failure to install furnace according to this installation instruc-
tion nullifies the furnace warranty.
SAFETY ALERT SYMBOLS
Safety Symbols alerting you to potential personal safety hazards.
Obey all safety messages following these symbols.
ƽ
WARNING
ƽ
CAUTION
avoid possible avoid possible
injury or death injury and/or property damage
INDEX
FURNACE SPECIFICATIONS .............................................................. 1
DIMENSIONS .................................................................. 1
WEIGHT ........................................................................ 1
MINIMUM CLEARANCE TO FLOORBOARDS , WALLS ,
& SIMILAR COMBUSTIBLE BUILDING MATERIALS .............................. 1-2
SAFETY INFORMATION .................................................................. 1-2
FURNACE INSTALLATION .................................................................. 2
WALL CUTOUT OPTIONS HORIZONTAL & VERTICAL
...................................... 2
VENT INSTALLATION (MODELS WITHOUT DOOR) HORIZONTAL & VERTICAL
................ 2
DUCTING HORIZONTAL & VERTICAL
.................................................... 2-3
Required Minimum Discharge Chart ............................................ 3
Flexible Ducting ...................................................................... 3
Floor Ducting ........................................................................ 3
OPTIONAL INSTALLATION - BOTTOM DISCHARGE KIT
.................................. 3
PROPANE GAS CONNECTION
............................................................ 3
ELECTRICAL CONNECTIONS
.............................................................. 3
Conductor Sizing Table ............................................................ 3
Thermostat Installation .......................................................... 3-4
SYSTEM CHECK TESTS .................................................................... 4
DIAGNOSTIC CHART ...................................................................... 4
PROPANE GAS PRESSURE .............................................................. 4
STATIC PRESSURE
........................................................................ 4
WIRING DIAGRAM .......................................................................... 4
ILLUSTRATIONS ............................................................................ 5
REPLACEMENT PARTS LIST & DRAWING .............................................. 6
SPECIFICATIONS (W.C. = Water Column)
MODEL 2540 LOW HIGH
BTU Input 25,000 40,000
Duct Static Pressure .10˝ W.C. .10˝ W.C.
12 Volt Amperage (AMPS) 7.2 16.8
Watts 86 202
Power Supply ( VOLT DC ) 12 12
Recommended Return Air 80 in 2 80 in 2
MINIMUM RETURN AIR 80 in 2 80 in 2
DIMENSIONS
WEIGHT ALL MODEL WIDTH HEIGHT DEPTH
Casing 16-1/2˝ 9-1/8˝ 23 1/2˝ - 26˝ FURNACE 39 lbs
Door 19-1/4˝ 9-1/4˝ 1/4˝ SHIPPING 46 lbs
Recess Bezel 20-9/16˝ 11-1/2˝
VENT 5˝ 5-3/8˝
MINIMUM CLEARANCE TO
FLOORBOARDS, WALLS & SIMILAR COMBUSTIBLE BUILDING MATERIALS
MUST BE PROVIDED THE FULL LENGTH AND WIDTH OF UNIT
HORIZONTAL TOP ----1/2˝ BOTTOM 3/16˝ SIDES ----1˝ REAR --1/2˝
VERTICAL TOP ----1/2˝ BOTTOM ----0˝ SIDES ----1˝ REAR --1/2˝
ENGLISH, FRANCAIS
(et Canada)
•Installation
Effective 1/08
LITERATURE NUMBER MPD 31230
hydro flame TM
8900-III-LD
2 Stage Series Furnace
MODEL 2540
Technical Installation Manual
Patent No US 6,464,000. 6,719,207. Other Patents Pending
9
