E. Specifications:
Display 5.6” Color TFT LCD
Resolution 960 (W) x 234 (H) Lines
Active Area 114.2 (W) x 83.5 (H) mm
Backlight CCFL
Input Signal NTSC/PAL(auto-switch)
Lamp Life 10,000 Hours
Audio Specifications:
Input Impedance 10 K-Ohms
Audio Output 0.3 W Maximum
Earphone 16 Ohms/32 Ohms
Bandwidth 15 kHz
Input Level 1 Vp-p
Power Source +12 VDC +/-15% (Ripple=0.5 Vp-p Max)
Power Consumption 8 Watts Max
Brightness 300 Nit Typical
Viewing Angle
Top 30 Degrees
Bottom 10 Degrees
Left/Right 45 Degrees
Operating Temperature 32°F - 140°F (0°C - 60°C)
Storage Temperature -4°F - 140°F (-20°C - +60°C)
Operating Humidity 85% RH Max.
Storage Humidity 85% RH Max.
Overall Dimensions 156.0W x 126.0H x 34.5D mm
Weight
12
© 2004 AEC, Hauppauge, NY
Composite video signal 1Vp-p/75ohm
500 Grams(16.0 Ounces)
