MULTI-TASKER™
3
ABOUT YOUR MULTI-TASKER™ 2
MT104-108
6-in 1-out S-Video Switcher Card
The MT104-108 is a 6-in (+1 internal input) 1-out
S-Video Switcher Card designed for use in
Multi-Tasker

enclosures. The MT S-Video SW
card enables 6 S-Video sources to be connected
and switched to a single display or recording
device. The MT104-108 is compatible with NTSC,
PAL and SECAM S-Video signals.
The MT104-108 card utilizes solid state switching
technology, and offers video bandwidth of
350 MHz, enabling it to pass high-resolution video
signals without degradation. Inputs are selected
via easy-to-use ASCII commands from a control
system or computer connected to the RS-232 port
of a Multi-Tasker™ enclosure.
Additionally, VIS (Vertical Interval Switching)
capability may be added by special order. This is a
feature that eliminates the "glitch" normally
associated with video switching when all input
video signals are gen-locked together. Also
available through ASCII control is “on-off” output
control.
TECHNICAL SPECIFICATION 3
FEATURES/DESCRIPTION MT104-108
GENERAL
Inputs
(6)
External Input Connectors
4-pin Mini DIN
Connectors
Internal Input Connector
(1) 10-pin IDC
Connector
Outputs (1)
Output Connector
(1) 4-pin Mini DIN
Connector
Approvals CE/FCC
Table 1. MT104-108 General
MECHANICAL MT104-108
Enclosure Slots Req'd One
Weight 0.43lb (0.19kg)
Shipping Weight 1 lb. (0.45kg)
Connector Panel Black
T° Operating 10°C to 40°C
T° Storage 0°C to 50°C
Humidity 90% non-condensing
MTBF (calc.) 55,000 hrs
Table 2. MT104-108 Mechanical
ELECTRICAL MT104-108
Input Signals
Analog
+/-1.5V (1.5Vp-p)
Impedance 75 Ohms
Type Differential
Return Loss -38dB @ 50MHz
Output Signals
Gain
1.05 (+/-5%)
Impedance 75 Ohms
Propagation Delay (Sync) 4nS max.
Rise/Fall time (Sync) 6nS max.
Differential Phase Error 01° @ 4.5 MHz
Bandwidth 350 MHz @ -3dB
Power
Power from Enclosure
+6V DC (80mA)
-6V DC (60mA)
Power Consumption 1 watt max.
Optional Accessories
MS8112CA
6ft., 15-pin HD Female
to 5 BNC Male
MS8102CA
6ft., 15-pin HD Female
to 5 BNC Male
Table 3. MT104-108 Electrical
