FREEZER LINER PARTS
6
For Model: ABB1922FEW11,ABB1922FEQ11,ABB1922FEB11
(White) (Bisque) (Black)
W10201592
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 67001291 Gasket, Foam (2)
3 12002497 Gear (2)
(Includes RH & LH)
4 67003905 Cover, Light
5 67004067 Shaft
6 Y12570701 Socket, Light
8 67006473 Screw (8)
9 A0282812 Bulb, Light
10 67001035 Housing, Frz. Light
11 67005871 Cover, Evaporator
12 67006425 Screw (7)
13 Bracket, Door
W10122147 Left
W10122148 Right
14 67003906 Housing, Lighting
15 W10167028 Clip, Evap. Motor
16
67005653 Switch, Light
18 Bracket, Basket
W10187668 Left
W10187667 Right
19 W10120018 Slide, Drawer (2)
20
67003731 Gasket, Bottom
21 Bracket, Slide
W10128118 Left
W10128119 Right
22 W10175909 Cover, Grille
23 W10167023 Shroud, Evap.Fan
24
2169142 Fan, Evaporator
25 W10121318 Grommet (2)
26
67003636 Motor, Evaporator
27 D7753903 Funnel, Drain
(Incl. # 28 & 29)
28 M0500703 Seal
29 B8381501 Gasket
30 12002355 Thermistor
31 67003924 Cover, Thermistor
32 67006406 Screw (6)
33 67006530 Screw
Following Parts Not Illustrated
67006095 Harness, Lights
(Freezer)
