SWITCHERS
3
required to correct the interference at his own
expense.
•
Any changes or modifications to the unit not
expressly approved by ALTINEX, Inc. could
void the user’s authority to operate the
equipment.
ABOUT YOUR MX2456RM
2
The MX2456RM is a video and audio switcher with
six VGA inputs, which can be connected to a single
VGA output and six stereo or balanced audio inputs,
which can be connected to a single stereo or
balanced audio output. It allows the non-
simultaneous connection of up to six computers or
six video and six audio sources to a monitor or
projector and to any audio system.
The MX2456RM can pass a variety of video signal
types: RGBHV, RGBS, RGsB, Component Video (Y,
R-Y, B-Y), S-Video and Composite Video. The
MX2456RM is controllable by using its built-in front
panel or through RS-232.
Each of the VGA inputs is ground loop isolated and
can promote individual equalization of video gain
according to different cable lengths.
The MX2456RM has a video bandwidth of 300 MHz
and an audio bandwidth of 40 kHz.
TECHNICAL SPECIFICATION
3
FEATURES/
DESCRIPTION
Audio
RGBHV
GENERAL
Inputs
6
6
Input
Connector
Six 5 conductor
terminal blocks
Six 15-pin HD-F
Outputs
1
1
Output
Connector
One 5 conductor
terminal block
One BNC Female
Compatibility
Stereo or balanced
audio
VGA, RGBHV,
RGBS,RGsB, &
C-Video
(Y, R-Y, B-Y)
Table 1. MX2456RM
General
MECHANICAL
MX2456RM
Width (inches)
1.75in (44mm)
Height (inches)
17.00 in (432mm)
Depth (inches)
9.00in (229mm)
Weight (pounds)
5lbs (2.28kg)
Finish
Gray
Front/Rear Panel
Lexan
T° Maximum
50°C
Humidity
90% non-condensing
MTBF (calculations)
40,000 hrs (min)
Table 2. MX2456RM Mechanical
ELECTRICAL
Audio
RGBHV
Input Signal
Differential
1.8V p-p
-
Analog
-
1.2V p-p
Composite Video
-
-
Impedance
10 k Ohms
75 Ohms
CMRR
80dB @ 10 Hz to
20k Hz
-
Input Sync
Signals
Composite,
Horizontal, &
Vertical
-
TTL (+/-)
Output Signals
Analog
-
1.2V p-p
Fall/ Rise Time
-
less than 2.4ns
Impedance
600 Ohms
75 Ohms
Crosstalk
80 dB @ 1kHz
-48dB @ 10 MHz
Differential
1.8Vp-p
-
Signal to Noise
Ratio
More than 95 dB
-
Bandwidth
10 Hz – 40 kHz
300MHz
Stereo Signal
Separation
More than 60dB
@ 20 kHz
-
Output Sync
Signals
Impedance
-
22 Ohms
Power
External Power
90V AC to 260V AC 50/60Hz
Power
Consumption
14 watts max.
Table 3. MX2456RM Electrical
