QUICKSTART
5.964-036.0 02/11
Maintenance and care
da
ily
monthly Kärcher Customer Service
1
A
B
ṇ Warning
Please observe the local provisions
regarding the wastewater treatment.
A Take the water discharge hose
from the support and lower above a
suited collection device.
B Then rinse the dirt water tank with
clear water.
2
A ṇ Warning
Please observe the local provisions
regarding the wastewater treatment.
A Loosen the lid for emptying the
fresh water - do not remove it fully.
Drain water.
Remove the lid with washer fully to
rinse off the fresh water tank.
3
A A Check fresh water filter; clean if
required.
4
A A Check brush for wear and tear and
clean it.
Check the brushes for wear (bristle
length at least 10 mm), replace if
required.
5
A B A Clean the vacuum lips on the vacu-
um bar, turn or replace if required
B Clean the suction channel.
