Karcher PUZZI 8-1 C - Manual (Page 17)

– 7
Technical specifications
Puzzi 8/1 C
Mains voltage V 220-240
Frequency Hz 1~ 50/60
Type of protection -- IPX4
Protective class II
Blower motor performance (max) W 1380
Nominal performance of blower motor W 1200
Air volume (max.) l/s 61
Negative pressure (max.) kPa (mbar) 23 (230)
Spray pump performance W 40
Spray pressure MPa 0,1
Spray pressure (max.) MPa 0,3
Spray volume I/min 1
Temperature of the cleaning solution (max.) °C 50
Filling quantity of fresh water l 8
Fill volume wastewater l 7
Length x width x height mm 575 x 330 x 445
Typical operating weight kg 9,8
Max. ambient temperature °C +40
Values determined to EN 60335-2-68
Sound pressure level L
pA
dB(A) 71
Uncertainty K
pA
dB(A) 1
Hand-arm vibration value m/s 2 <2,5
Uncertainty K m/s 2 0,2
Power cord H05VV-F 2x1,0 mm 2
Part no.: Cable length
EU 6.647-263.0 7.5 m
GB 6.647-264.0 7.5 m
CH 6.647-265.0 7.5 m
17 EN
