Technical specifications
Main Supply
Voltage
V 400
Current type Hz 3~ 50
Connected load kW 9,2
Protection (slow, char. C) A 16
Maximum allowed net impedance Ohm (0.167
+j0.104)
Type of protection IPX5
Extension cable 10 m mm 2 2,5
Extension cord 30 m mm
2
4
Water connection
Max. feed temperature
°C 60
Min. feed volume l/h (l/min) 1200 (20)
Suck height from open container (20 °C) m 0,5
Max. feed pressure MPa (bar) 1 (10)
Performance data
Working pressure
MPa (bar) 25 (250)
Max. operating over-pressure MPa (bar) 27,5 (275)
Flow rate l/h (l/min) 1000 (16,67)
Nozzle size 047
Detergent suck in l/h (l/min) 0...80 (0...1,3)
Max. recoil force of hand spray gun N 62
Values determined as per EN 60355-2-79
Noise emission
Sound pressure level L
pA
dB(A) 76
Uncertainty K
pA
dB(A) 3
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 92
Hand-arm vibration value
Hand spray gun
m/s
2
3,6
Spray lance m/s 2 4,2
Uncertainty K m/s
2
1
Fuel
Amount of oil
l 1,2
Oil grade SAE 90
Dimensions and weights
Length
mm 608
Width mm 546
Height mm 1174
Weight kg 70
20 EN
