Karcher NT 45-1 Tact Te - Manual (Page 14)

– 2
1 Electrodes
2 Suction hose
3 Cable hook
4 Air outlet, working air
5 Suction head lock
6 Wheel
7 Air inlet, motor cooling air
8 Suction head
9 Steering roller
10 Steering roller bow
11 Dirt receptacle
12 Suction support
13 Floor nozzle
14 Suction tube
15 Carrying handle
16 Filter cover
17 Bender
18 Rotary switch for suction output (min-
max)
19 Indicator lamp
20 Socket
21 Automatic filter dedusting
22 Main switch
23 Flat fold filter
24 Filter dedusting
25 Floor nozzle holder
26 Holder for crevice nozzle
27 Holder for suction pipes
28 Power cord
29 Nameplate
Caution
The flat pleated filter must always be in
place while vacuuming.
Only for appliances with built-in socket:
Static charge is deflected by providing
earthing to the connection nozzles. This
prevents the formation of sparks and cur-
rent shocks due to attachments (option)
with electrical conductivity.
– To vacuum fine dust, you can also use
an additional paper filter bag, a fleece
filter bag (option) or a membrane filter
(option).
Illustration

Release and remove the suction head.
 Insert the paper filter bag, fleece filter
bag (option) or membrane filter (option).
 Insert and lock the suction head.
Caution
Please note the following when switch-
ing from wet to dry vacuum cleaning:
If you vacuum dry dust while the filter ele-
ment is still wet the filter will become ob-
structed and may be damaged beyond
repair.

Dry the wet filter properly before use or
replace it with a dry one.
 Change the filter, if required, according
to instructions under the section "Main-
tenance and Care".
Note: For permanent wet vacuum cleaning
it is advisable to use a PES flat pleated filter
(see filter systems).
Illustration

Remove the brush strips.
 Install the rubber lips.
Note: The structured side of the rubber lips
must point outwards.
– If the appliance is used to vacuum wet
dirt, the paper filter bag, the fleece filter
bag (option) or the membrane filter (op-
tion) must always be removed.
– It is recommended to use a special filter
bag (wet) (see Filter systems).
Device elements
Start up
Anti-static system
Dry vacuum cleaning
Installing the paper filter bag/fleece filter
bag
Changeover from wet to dry vacuum
cleaning
Wet vacuum cleaning
Inserting the rubber lips
Remove the paper filter bag/fleece filter
bag
14 EN
