Haltech I/O Expander 12
Quick Start Guide
Congratulations on purchasing a Haltech I/O Expander 12
This Plug and Play product allows the user the ability to increase the functionality
of their Haltech ECU by using the Haltech CAN system which is fitted to all
Platinum Series ECU's.
The Haltech I/O Expander 12 instantly makes available 12 additional user configurable
inputs and outputs. Simply plug in the CAN cable and start using your extra I/O.
This quick start guide will walk you through installation of the Haltech I/O Expander 12
into a vehicle. This guide is accompanied by the full service manual located
on the software CD provided with the ECU that you or your tuner will need to refer to
before completing your installation and configuration. The Manual can also be
downloaded from the Haltech website
www.haltech.com .
Included in Haltech I/O Expander 12 Kit
• Haltech I/O Expander 12
• Haltech CAN direct connection cable Black 600mm
• Quick start guide
• Haltech Sticker
Optional Accessories ( Sold Separately )
• I/O Expander 12 – Flying Lead Harness ( HT049902 )
• I/O Expander 12 – Plug and Pin Set ( HT030007 )
• CAN Cable Hub Connection White available in various sizes 75mm up to 3600mm
( Please contact Haltech for sizes and prices )
• CAN Cable Direct Connection Black available in various sizes 75mm up to 3600mm
( Please contact Haltech for sizes and prices )
