UFL-420/440 water FiLtration system
18 P/N 1010873 Rev. G 03/12
A.J. Antunes & Co.
replacement parts Ufl-420/440
1 2190150 Union Assembly 1” NPT 1
2 2190144 Nipple, hex 3/4” NPT x 1 1/2” Lg 1
3 2180181 Ring, Lock 2
4 7000442 end cap Kit Incl. 1 of P/N 7000413, 1
1 of P/N 2180181, and
1 of P/N 2180228
5 7000413 o-ring Replacement Kit 1
Incl. 4 of PN 0200236, 2 of
PN 0200235, and 1 of PN 2140153
6 7000411 cartridge Replacement Kit 1
UFL-420 only (Includes o-ring
Replacement Kit P/N 7000413)
7000412 cartridge Replacement Kit 1
UFL-440 only (Includes o-ring
Replacement Kit P/N 7000413)
7 0504065 clamp, 4” Filter 1
8 308P157 Screw, Tap #8-32 x 3/8” ** 12
9 2180201 Housing, Filter UFL-420 1
2180202 Housing, Filter UFL-440 1
10 4040183 Solenoid Valve 24 VAC 1
Nc 3/4” NPT
12 0021338 Flow Regulator Assembly *** 1
5 gPM - UFL-420 (green)
0021337 Flow Regulator Assembly *** 1
10 gPM - UFL-440 (Black)
13 0504033 Bracket, Mounting 1
14 0400334 Strain Relief - Small 1
15 040P333 Nut, Lock ** 1
16 0503983 Control Housing 1
17 0700665 Power Supply, 120 V (5-20P) 1
0700666 Power Supply, 230 V (CEE 7/7) 1
0700682 Power Supply, 220 V (hKh-01) 1
China only
19 4060355 Terminal Block, 3-Pole 1
20 306P101 Nut, hex #6-32 ** 2
21 308P143 Nut, hex KePS #8-32** 2
22 304P105 Nut, hex KePS #4-40 ** 4
23 7000440 Timer, 24 VAC 1
24 7000359 cover gasket Kit 1
25 7000362 control housing cover Kit 1
Incl. Items 23 and 25
26 1001116 Label, Timer 1
27 2190148 Plug, Pipe 1” NPT 1
28 2190147 Nipple, hex 1” NPT 2
33* 2140153 Lubricant, high-vacuum grease 1
34* 0700636 Wire Set 1
35* 0700637 Wire harness 1
36* 1001143 Label, Wiring Diagram 1
37* 1001133 Label, Inlet ** 1
38* 1001135 Label, Drain ** 1
39* 1001134 Label, Permeate ** 1
40* 1010873 owner’s Manual 1
Item part Description Qty.
no.
Item part Description Qty.
no.
* not shown
** only available in packages of 10.
*** warninG: Use only a 5 GPm Flow regulator
with UFL-420 units and a 10 GPm Flow regulator
for UFL-440 units. Use of the wrong Flow regulator
will void the system warranty.
replacement parts can be purchased from an authorized dealer. contact antunes
filtration technologies at 1-630-754-1000 or toll free in the United states at 1-800-253-2991
