4
ENGLISH
Safety
instruction
For tapping, use ROTHENBERGER high-performance thread-tapping oil art. no. 6.5010. This oil
is not suitable for tapping drinking water pipes!
Alternatively, you can use ROTHENBERGER high-performance thread-tapping fluid, art. no.
6.5015. This fluid is suitable for tapping all pipelines (including drinking water pipelines).
Precise thread-tapping is only possible if the number on the slot of the thread-tapping head
corresponds with the number on the thread jaw!
Use only raw material that is in perfect condition for tapping threads.
If you use deformed and / or pipes cut off at an angle, it is not possible to tap threads that
conform to the relevant standards!
Use the thread-tapping head and the corresponding thread-tapping jaws that matches the
thread size! Secure the thread-tapping head correctly on the tool carriage.
Do not place the thread-tapping head directly and unprotected on the floor and handle it with
care!
Ensure that the thread-tapping oil runs on the thread-tapping jaws!
Apply anti-rust grease if the machine is not going to be used for an extended period!
Overview
A
1 T-handle
6 Profile
pin
2
Selector pin (silver)
7
Locking lever, body
3
Selector pin (black)
8
Locking lever, clamping head
4
Threaded pin (fast adjustment)
9 Cam
plate
5 Profile
body
10 Selector
block
Installing the thread jaws from and in the thread-tapping head
B
Wear gloves in order to prevent cut injuries to the hands caused by the
thread jaws!
Î
Pull the parking lever in the “A” direction in order to open the thread jaws.
Î
Insert the selector pin (silver colour) into the selector block of the thread jaws.
Î
Insert the thread jaws with the same number as on the respective thread-tapping head and
make sure it engages audibly.
Î
Ensure that the numbers on the thread-tapping head and on the thread jaws are on the
same side.
Changing the thread size
C
Î
Insert the selector pin into the selector block with the necessary thread size.
Î
The size is shown on the respective selector block.
Î
Use the silver selector pin and the block for ½” … 1” and the black selector pins for 1 ¼”...
2”.
Î
Lower the thread-tapping head and insert the T handle, pressing in fully in the “B”
direction until the thread-tapping jaws engage in the working position
