TRANSCODERS
5
CONNECTOR
CONNECTOR
TYPE
DESCRIPTION
5
BNC
HORIZONTAL
SYNC
6
BNC
VERTICAL SYNC
Table 5. Main output RGBSHV output configuration
6.3 POWER
The power module is configurable to 110 or 220
volts. To reconfigure the unit, squeeze together the
two prongs of the fuse module of the power module
and pull it out from its socket. Remove the fuse box
and install it to display the desired voltage in the
voltage window. Place the fuse box back in its
socket.
PIN
OUTPUT SIGNALS
1
RED
2
GREEN
3
BLUE
4
Not used
5
Not used
6
Ground
7
Ground
8
Ground
9
Not used
10
Not used
11
Not used
12
Not used
13
HORIZONTAL SYNC
14
VERTICAL SYNC
15
Not used
Table 6. RGBHV output on 15-pin connector
6.4 CABLE REQUIREMENTS
Any 3-BNC, 4-BNC, or 5-BNC coaxial cable can be
used as an input cable. The output cable type
depends on the display device input port and the
output port used on the TR6102HD. For example, a
VGA monitor can be directly connected to Output 1
and 2. A multi-sync monitor with BNC input can be
connected directly to the main output. Other
combinations may require cables with a 5-BNC or
15-pin HD (VGA) connector on one end and a
connector compatible with the display device on the
other end.
ACESSORIES
7
Model No.
Description
15-PIN VGA TO 5 BNC
MS8102CA
15-pin HD Male to 5 BNC-6ft
MS8104CA
15-pin HD Male to 5 BNC-15 ft
MS8106CA
15-pin HD Male to 5 BNC Female-6ft
MS8112CA
15-pin HD female to 5 BNC - 6ft
MS8114CA
15-pin HD female to 5 BNC - 15ft
STANDARD 15-PIN VGA (M) to (M)
Coaxial Cable
CB3703MR 3 feet, 15-pin HD (M) to 15-pin HD (M)
CB3706MR 6 feet,15-pin HD (M) to 15-pin HD (M)
CB3715MR 15 feet,15-pin HD (M) to 15-pin HD (M)
CB3725MR 25 feet,15-pin HD (M) to 15-pin HD (M)
CB3750MR 50 feet,15-pin HD (M) to 15-pin HD (M)
CB3775MR 75 feet,15-pin HD (M) to 15-pin HD (M)
CB37100MR 100 ft,15-pin HD (M) to 15-pin HD (M)
4 BNC TO 4 BNC COAXIAL CABLE
CB4100MR Bulk cable 4 coaxes (500 ft minimum)
CB4106MR 6 feet, 4 BNC to 4 BNC coaxial cable
CB4112MR 12 feet, 4 BNC to 4 BNC coaxial cable
CB4125MR 25 feet, 4 BNC to 4 BNC coaxial cable
CB4150MR 50 feet, 4 BNC to 4 BNC coaxial cable
CB4175MR 75 feet, 4 BNC to 4 BNC coaxial cable
CB41100MR 100 feet, 4 BNC to 4 BNC coaxial cable
5 BNC TO 5 BNC COAXIAL CABLE
CB4200MR Bulk cable 5 coaxes (500 ft minimum)
CB4203MR 3 feet, 5 BNC to 5 BNC coaxial cable
CB4206MR 6 feet, 5 BNC to 5 BNC coaxial cable
CB4212MR 12 feet, 5 BNC to 5 BNC coaxial cable
CB4225MR 25 feet, 5 BNC to 5 BNC coaxial cable
CB4250MR 50 feet, 5 BNC to 5 BNC coaxial cable
CB4275MR 75 feet, 5 BNC to 5 BNC coaxial cable
CB42100MR 100 feet, 5 BNC to 5 BNC coaxial cable
