EN
16
Overall view
Description of the
appliance
1. Upper rack
2. Upper sprayer arm
3. Tip-up compartments
4. Rack height adjuster
5. Lower rack
6. Lower sprayer arm
7. Cutlery basket
8. Washing filter
9. Salt dispenser
10. Detergent and rinse aid dispensers
11. Data plate
12. Control Panel
***
***
Only in completely built-in models.
*
Only available in selected models.
The number and type of wash cycles and options may vary depending on the dishwasher model.
Control panel
Half load button
Delayed start button
ON/OFF/Reset
button
ON/OFF
indicator light
Low salt
indicator light
Select wash
cycle button
Low rinse aid
indicator light
Multi-functional
tablets button
Multi-functional
tablets indicator light
Half load upper rack
indicator light
Half load lower rack
indicator light
Delayed start
indicator lights
Wash cycle number
light-up indicator
