Description of the appliance, Overall view, Control panel – Indesit DSG-5731 User Manual
Page 19: Display
EN
19
Overall view
Description of the
appliance
1.
Upper rack
2.
Upper sprayer arm
3.
Tip-up compartments
4.
Rack height adjuster
5.
Lower rack
6.
Lower sprayer arm
7.
Cutlery basket
8.
Washing filter
9.
Salt dispenser
10.
Detergent and rinse aid dispensers
11.
Data plate
12.
Control Panel
***
***
Only in completely built-in models.
*
Only available in selected models.
The number and type of wash cycles and options may vary depending on the dishwasher model.
Low Salt
indicator light
Low Rinse aid
indicator light
Washing
indicator light
Drying indicator light
Delayed start
indicator light
Half load indicator light
Multi-functional tablets
indicator light
Time remaining
light-up display
Wash cycle number
light-up indicator
Control panel
Start/Pause button
and indicator light
Half load
button
Display
Delayed start
button
ON/OFF/RESET
button
Select wash
cycle button
Multi-functional
Tablets button
Display
