Indesit UFAN300NFUK - Manual (Page 5)

GB
5
Start-up and use
WATER LEVEL
MAX
W A TER LEVEL
MAX
W
A
TER LEVEL
MAX
Starting the appliance
! Before starting the appliance, follow the installation
instructions (see Installation).
! Before connecting the appliance, clean the
compartments and accessories well with lukewarm water
and bicarbonate.
! The appliance comes with a motor protection control
system which makes the compressor start approximately 8
minutes after being switched on. The compressor also
starts each time the power supply is cut off whether
voluntarily or involuntarily (blackout).
1. Insert the plug into the socket and make sure that the
green POWER indicator light illuminates (the
TEMPERATURE ADJUSTMENT knob must be in the
position).
2. Turn the TEMPERATURE ADJUSTMENT knob to an
average value and press the SUPER FREEZE button
(rapid freezing): the SUPER FREEZE indicator light
will illuminate. It will switch off once the freezer has
reached its optimal temperature. At this point food may
be placed inside the appliance.
Using the freezer to its full potential
• Use the TEMPERATURE CONTROL knob to adjust the
temperature.
= warmest
= coldest
ECO is the optimal temperature for energy saving levels.
We recommend, however, a medium position.
• Do not re-freeze food that is defrosting or that has
already been defrosted. These foods must be cooked
and eaten (within 24 hours).
• Fresh food that needs to be frozen must not come into
contact with food that has already been defrosted. Fresh
food must be stored in the top FREEZER and STORAGE
compartment.
• Do not place glass bottles which contain liquids, and
which are corked or hermetically sealed in the freezer
because they could break.
• The maximum quantity of food that may be frozen daily is
indicated on the plate containing the technical properties
located within the freezer (for example: Kg/24h: 4).
• To freeze (if the freezer is already operating):
- for small quantities which are less than those indicated
on the data plate, press the rapid freezing SUPER
FREEZE button (corresponding indicator light
illuminates), insert the food and close the door. The
function is disabled automatically after 24 hours or when
optimal temperatures have been reached (indicator light
goes out);
- for large quantities which are greater than the maximum
load indicated on the data plate, hold down the rapid
freezing SUPER FREEZE button until the corresponding
indicator light begins to flash. After 24 hours the indicator
light stops flashing and remains on constantly. Place the
food inside the freezer and close the door. After another
24 hours, the function will be disabled automatically
(indicator light goes out).
! Do not open the door during freezing.
! If there is a power cut or malfunction, do not open the
freezer door. This will help maintain the temperature
inside the freezer, ensuring that foods are conserved for
at least 9 -14 hours.
Ice 3 ice tray
The fact that they are situated on the top part of the
freezer drawers ensures greater cleanliness: the ice no
longer comes into contact with the food placed inside
the freezer compartment; furthermore, the dripping of
the water during filling is avoided (a lid to cover up the
hole after filling with water is also provided).
1. Pull out the tray by pushing it up.
Check that the tray is ompletely empty and fill it with
water through the opening provided.
2. Take care not to exceed the level indicated (MAX
WATER LEVEL). Excess water prevents the ice cubes
from dispensing (if this happens, wait for the ice to
melt and empty the tray).
3. Turn the tray 90°: due to the connected compartments
each mould fills with water (see diagram).
4. Close the opening with the lid provided and put the
tray back, placing the top part in the corresponding
housing and allowing it to drop in again.
5. When the ice has formed (minimum time
approximately 8 hours) knock the tray against a hard
surface and wet the outside so that the ice cubes
come loose and take them out through the opening.
