Description of the appliance
Overall view
Control panel
ELECTRIC HOTPLATE
control knobs
SELECTOR
knob
VARIABLE GRILL
knob
THERMOSTAT
indicator light
ACTIVE HOTPLATE
indicator light
Control panel
GRILL
rack
DRIPPING
pan
GUIDE RAILS
for the sliding racks
position 3
position 2
position 1
Adjustable foot
Adjustable foot
position 5
position 4
Tray for
Catching
Overflows
Electric
plates
Electric
plates
