2
GB
Installation
! Before placing your new freezer into operation please
read these operating instructions carefully. They contain
important information for safe use, for installation and for
care of the appliance.
! Please keep these operating instructions for future
reference. Pass them on to possible new owners of the
appliance.
Positioning and connection
Positioning
1. Place the appliance in a well-ventilated humidity-free
room.
2. Do not obstruct the rear fan grills. The compressor and
condenser give off heat and require good ventilation to
operate correctly and save energy.
Electrical connections
After the appliance has been transported, carefully place
it vertically and wait at least 3 hours before connecting it
to the electricity mains. Before inserting the plug into the
electrical socket ensure the following:
• The appliance is earthed and the plug is compliant
with the law.
• The socket can withstand the maximum power of the
appliance, which is indicated on the data plate located
on the bottom left side of the fridge (e.g. 150 W).
• The voltage must be in the range between the values
indicated on the data plate located on the bottom left
side (e.g. 220-240V).
• The socket is compatible with the plug of the
appliance. If the socket is incompatible with the plug,
ask an authorised technician to replace it (see
Assistance). Do not use extension cords or multiple
sockets.
! Once the appliance has been installed, the power supply
cable and the electrical socket must be easily accessible.
! The cable must not be bent or compressed.
! The cable must be checked regularly and replaced by
authorised technicians only (see Assistance).
! The manufacturer declines any liability should these
safety measures not be observed.
WARNING: THIS APPLIANCE MUST BE EARTHED.
Replacing fuse covers:
When replacing a faulty fuse, a 13amp ASTA approved
fuse to BS 1362 should always be used and the fuse cover
re-fitted. If the fuse cover is lost, the plug must not be used
until a replacement is obtained.
Replacement fuse covers:
If a replacement fuse cover is fitted, it must be of the correct
colour as indicated by the coloured marking or the colour that
is embossed in words on the base of the plug.
Changing the plug: Removing the plug
If your appliance has a non-rewireable moulded plug and
you should wish to remove it to add a longer cable or to re-
route the mains cable through partitions, units etc. please
ensure that either:
- The plug is replaced by a fused 13amp rewireable plug
bearing the BSI mark of approval.
or
- The mains cable is wired directly into a 13amp cable outlet,
controlled by a switch (in compliance with BS 5733) which is
accessible without moving the appliance.
Disposing of the plug
Cut off and dispose of the supplied plug if it does not fit
your socket. The cable should be cut as close as possible
to the moulded plug. Remove the fuse.
WARNING: To avoid a shock hazard do not insert the
discarded plug into a socket anywhere else.
Fitting a new plug
IMPORTANT:
WIRES IN THE MAINS LEAD ARE COLOURED IN
ACCORDANCE WITH THE FOLLOWING CODE...
Green and Yellow - Earth
Blue - Neutral
Brown - Live
As the colours of the wires in the
mains lead may not correspond with
the coloured markings identifying the
terminals in your plug, proceed as
follows:
- Connect Green and Yellow wire to terminal marked
'E' or or coloured Green and Yellow.
- Connect Brown wire to terminal marked 'L' or coloured
red or brown.
- Connect Blue wire to terminal marked 'N' or coloured
Black or Blue.
If a 13amp plug (BS 1363) is used it must be fitted with a
13amp fuse. A 15amp plug must be protected by a 15amp
fuse, either in the plug or adaptor or at the distribution board.
If you are in any doubt about the electrical supply to your
machine, consult a qualified electrician before use.
CE Marking certifies that this appliance conforms to the
following EEC directives :
Low Voltage Equipment - 73/23/EEC & 93/68 EEC
Electromagnetic Compatibility 89/336/EEC, 92/31/EEC &
93/68/EEC
