Product Specifications
GENERAL
Channels:
All current USA, International,
Canadian, and
Weather Channels
Controls:
Volume & power on/off knob,
Squelch knob, Ch. up/down,
Ch. 16/Ch. 9 or Triple watch,
1 or 5 Watt, Light or Keypad
lock, Push to talk, UIC.,
Mem Scan, Weather Alert,
All N.O.A.A WX Channels.
Status Indicators:
Channel readout,
Battery Strength Indicator,
Lock, 1W/5W, US/INT/CAN,
Triple Watch, TX, Mem, Scan,
WX Alert, WX
Channel Display:
Backlit LCD
Channel Selector:
Up/down
Antenna Connector:
SMA type (female)
Size:
150 mm (H) x 57 mm (W) x
37 mm (D) 5 7/8” (H) x 2 1/4”
(W) x 1 1/2” (D)
Weight:
13.1 ounces (Batteries installed)
Charge Power Source:
12V DC Plug (included)
(optional) AC Adapter ACATL
Antenna Impedance:
50
W
Speaker:
4
W
1.0W
Operating Temperature Range:
-20
°
c ~
+50°
c
Power Source:
NiMH rechargeable battery/
1350 mAH or 6 AA Alkaline
batteries (batteries not included)
Battery Input Voltage:
9v Alk./7.2v NiMH
TRANSMITTER
Frequency Range:
156 ~ 158 MHz
Frequency Stability:
±500Hz
Power Output:
5 watt, 1 Watt - selectable
Spurious Emissions:
5W, -70 dBc
Current Drain:
High - 1.3 Amps
Low - 600 Milliamps
Modulation:
FM ±5 KHz deviation
(FCC designator F3E)
RECEIVER
Receiver Type:
Dual conversion
superheterodyne
Signal-To-Noise:
40 dB Nominal
Frequency Range:
156 ~ 164 MHz
Receiver Sensitivity:
0.25 µv AT 12 dB SINAD
Audio Output Power:
1 Watt
