Able of, Ontents – Antec Quiet Computing Mini Skeleton-90 User Manual
Page 2
1
T
ABLE OF
C
ONTENTS
I
NTRODUCTION
1.1
Case Specifications……………………………………………………………………………………….. 3
1.2
Diagram………………………………………………………………………………………………………… 3
1.3
EP-90 Power Supply Specifications……………………………………………………………….. 4
H
ARDWARE
I
NSTALLATION
G
UIDE
2.1
Removing/Replacing the Component Tray…………………………………………………… 5
2.2
Motherboard Installation……………………………………………………………………………… 5
2.3
5.25” Device Installation………………………………………………………………………………. 6
2.4
2.5” Device External Installation…………………………………………………………………… 6
2.5
2.5” Device Frame-Mounted Installation……………………………………………………… 7
2.6
Removing the Frame Side Screen Panels………………………………………………………. 7
C
ONNECTING THE
F
RONT
I/O
P
ORTS
3.1
USB 2.0 Ports………………………………………………………………………………………………… 8
3.2
Audio Ports…………………………………………………………………………………………………… 8
3.3
Power Switch / Reset Switch / Hard Disk Drive LED Connectors……………………. 9
C
OOLING
S
YSTEM
4.1
150mm Overhead TriCool™ Fan.………………………………………………………………….. 10
4.2
70mm Intake Fan……………………………………………………………………………………….. 10
