PowerBrick User’s Manual
Power Button
PC Card slot
Compact Flash
Figure 2.2: Front side of PowerBrick
Connect all applicable cables such as:
? Keyboard
? Mouse
? Monitor
? Power supply cable
Optional device cables or units that you provide yourself could include the following:
? USB cable
? Speaker and microphone cables
? RJ45 Ethernet TP cable
? Parallel port printer-cable
? Serial port cable
2
