Duty cycle 35% 100 A
Main voltage
230 VAC 115 VAC
Frequency 50/60 Hz
Cos φ 0.99
Efficiency 0.85
Current range 5 – 100 A
Off load voltage 80 V
Output current 60% 80 A
Output current 35% 100 A
Absorbed power 60% 2.4 KVA
Absorbed power 35% 3.1 KVA
Main current 60% 11.7 A 23.4 A
Main current 35% 15 A 30.2 A
Protection class IP 21
Insulation class H
Dimensions cm 12X30X21
Weight Kg 3.5
Electrodes diameter 3.25
Electrodes type R – B – I
Duty cycle 60% 200 A
Main voltage 230 VAC
Frequency 50/60 Hz
Cos
φ 0.99
Efficiency 0.85
Current range 1 – 140 A
Off load voltage 60 V
Output current 100% 110 A
Output current 60% 140 A
Absorbed power 100% 3.5 KVA
Absorbed power 60% 4.7 KVA
Main current 100% 17 A
Main current 60% 22.7 A
Protection class IP 23
Insulation class H
Dimensions cm 18X25X40
Weight Kg 7.9
Electrodes diameter 3.25 (4)
Electrodes type R – B – I (c-al)
