2.2.2 Output DC Current Ranges
All outputs are within the specified limits of regulation when each output is
subjected to the conditions listed below.
Table 3. DC Input Line Requirements
DC Nominal
Voltage
Minimum
Current
Maximum
Current
Combined Output
+12 V1 DC 1.0 A 20A
+12 V2 DC 1.0 A 20A
+12 V3 DC 1.0 A 20A
574W
+5 V DC 0.2 A 20A
+3.3 V DC 0.1 A 20A
160W
- 12 V DC 0.0 A 0.3A 3.6W
+5 V SB 0.05A 2.5A 12.5W
600W
NOTE:
1)The combined power output of +5V and +3.3V shall not exceed 160W.
The combined power output of +5V,+3.3V and +12V shall not exceed 574W
3)Input voltage is 110-240Vac ,When peak load.
2.2.3 Output Voltage Line Regulation
The following table specifies line regulation as measured from
minimum to maximum load including the transient response
requirements as detailed in this document.
Table 4. DC Output Tolerance Specifications
DC Nominal Output Output Voltage Tolerance
+12V1 DC ±1%
+12V 2DC ±1%
+12V 3DC ±1%
+5V DC ±1%
+3.3V DC ±1%
-12V DC ±2%
+5V SB ±1%
2.2.4 Cross Regulation
The power supply DC outputs perform within all line and load specifications
Regardless of the static or transient loads on any of the outputs.
