5. Fan Specification:
FAN MODEL: SF08025S9M302
1) Rated Voltage : 12VDC
2) Operating Voltage Range : 10.2 ~13.8VDC
3) Rated Speed（only fan） : 2700RPM ±10%
4) Static Pressure : 3.04 mm-H
2
O
5) Air Flow : 35.7 CFM
6) Rated Current : 0.16 A +/-0.02
7) Rated Power : 1.92WATTS
8) MAX Noise Level : 29.0 dB(A)
9) Operating Temperature : -10 to 70
0
C
10) Storage Temperature : -40 to 70
0
C
11) Bearing System : Sleeve Bearing
12) Connector : 3 pin
13) Weight :57.0g
