3. Features and Specifications:
Main features:
Supports all new LGA7751155//1156/ AM2+AM3 FM1 micro-processors
92x92x25mm sleeve fan for silent operation
Specifications：
Dimensions
Heat sink : 98X88X35 mm
12VDC Fan : 92x92 x 25mm
Material AL
Bearing Sleeve Bearing
Rated speed
Cooler 600~2200 RPM +/-10%
Single fan 600~2200 RPM +/-10%
Rated power 2.16 W
Noise level 10~22.0 dBA
Air flow 45.26CFM Max.
Current 0.18A
Life hours Sleeve: 30,000
Connector 4PIN PWM(2510)
Application LGA 775/1155/1156 and AM2/AM3/AMD FM1
Thermal
resistance
0.388°C/W
TDP 65~95W
Thermal type Stars-420
weight 185g(Cooler only)
