5. Fan Specification:
FAN MODEL: SF09025SRL402-PWM
1) Rated Voltage : 12VDC
2) Operating Voltage Range : 10.2 ~13.8VDC
3) Rated Speed(Only fan) : 600~2200RPM ±10%
4) Static Pressure : 1.7 mm-H
2
O
5) Air Flow : 40.9CFM
6) Rated Current(max) : 0.18 A
7) Rated Power : 2.16WATTS
8) Noise Level : 25.0 dB(A)
9) Operating Temperature : -10 to 70
0
C
10) Storage Temperature : -40 to 70
0
C
11) Bearing System : Sleeve Bearing
12) Connector : 4 PIN PWM(2510)
13) Weight : 56.0 g
