3. Features and Specifications:
Main features:
Aluminum High-density fin Heat Sink
2 thermally improved copper heat-pipes
92x25mm Sleeve bearing fan for silent operation
heat-sink with large base for optimal heat conductivity
Specifications:
Dimensions
Heat sink : 96.5X51X125 mm
12VDC Fan : 92X92X25 mm
Material AL+CU
heatpipe Two(2) 6mm all copper U-shaped
Bearing Sleeve Bearing
Rated speed
Cooler 2000 RPM
Only fan 2000 RPM
Rated power 2.4 W
Noise level 19.0 dBA
Air flow 38.4 CFM
Current(MAX) 0.20A
Life hours Sleeve: 30,000
Connector 3 pin, main board
Application
1. Intel LGA775/1156
2. AM2/AM3
3. AMD FM1
TDP(Watt) 95 W
Thermal resistance 0.285°C/W
Thermal type Stars-420
weight 358 g(Cooler only)
