5. 5. 5. 5. Fan Fan Fan Fan Specification: Specification: Specification: Specification:
FAN FAN FAN FAN MODEL: MODEL: MODEL: MODEL: SF SF SF SF120 120 120 12025N7H4-PWM 25N7H4-PWM 25N7H4-PWM 25N7H4-PWM
1) Rated Voltage : 12VDC
2) Operating Voltage Range : 10.2 ~13.8VDC
3) Rated Speed(Single fan) : 600～1800RPM ±10%
4) Static Pressure : 2.86 mm-H
2
O
5) Air Flow : 74.63CFM Max.
6) Rated Current : 0.18A
7) Rated Power : 2.16WATTS
8) Noise Level : 10.0～22.0 dB(A)
9) Operating Temperature : -10 to 70 0 C
10) Storage Temperature : -40 to 70 0 C
11) Bearing System : Nano precision Bearing
12) Connector : 4 PIN PWM(2510)
13) Weight : 124 g
