5. Fan Specification:
FAN MODEL: SF12025B1H4W3-PWM
1) Rated Voltage : 12VDC
2) Operating Voltage Range : 10.2 ~13.8VDC
3) Rated Speed(Only fan) : 600～1650RPM ±10%
4) Static Pressure : 2.12 mm-H
2
O
5) Air Flow : 71.12CFM
6) Rated Current : 0.15A
7) Rated Power : 1.80WATTS
8) Noise Level : 10～25 dB(A)
9) Operating Temperature : -10 to 70 0 C
10) Storage Temperature : -40 to 70 0 C
11) Bearing System : Ball Bearing
12) Connector : 4 pin
13) Weight : 124 g
