4.PSU:SFX-300W-PFC-PSU:
SFX-300W-E-PSU: 220V, 300W psu,80mm FAN,20+4pin,2SATA,4IDE,1FLOPPY,12V4pin,
PCIE6+2pin 1PCS,Matel case,1.5M Normal power cord.
Features
Intel SFX12V 3.0 Specification Compliant Supports the
newest Intel and AMD Micro-Processors I/O Short Circuit &
Overload /OVP/OLP/ SCP Protection SATA Power
Connector
Dimensions 100mm(L)X125mm(W)X64mm(H)
Version SFX 12V 3.0
Connectors
20+4pin 1PCS, 12V 4pin 1PCS,SATA 2PCS, IDE (Molex)
4pin 4PCS, Floppy 4pin 1PCS
Cables
20+4pin 1PCS, 12V 4pin 1PCS,2SATA 1PCS,
2IDE/Floppy 1PCS,2IDE 1PCS
Case 0.6mm Matel case
Rated Voltage 200~240 Vac
Frequency 50~60 Hz
Current 3A for 230VAC
Hold-up Time 16 ms(min)
Nom. Power 300W
P.G. Signal 100~500ms
Voltage Protection
+12V trip point 13.4V - 15.6V
+5V trip point 5.74V - 7.0V
+3.3V trip point 3.76V - 4.3V
Noise Level 21 dBA Max
Cooling 1 x80mm fan
MTBF 100,000 Hours
Application
Intel Pentium 4,Intel Celeron D,Intel Core 2,Intel Core 2
Due,Intel Core 2 Extreme/AMD Athlon 64X2,AMD Athlon
64 FX,AMD Athlon 64,etc.
Operating
Temperature
0~40℃
Storage Temperature -20~60℃
Warranty 2 Years
