Blodgett 40GS-KLS Series - Manual (Page 26)

24 OM-40GS-KLS
Parts List
Key Description Part No.
G GAS VALVE, PIPING ASSY 139197
3 WATER LEVEL ELECTRODE 074665
4 ELECTRICAL COMPONENTS ASSEMBLY 139060
5 IGNITION MODULE BOX ASSEMBLY 127334
6 ELBOW, 90º UNION, 1/2” NPT 005495
7 NIPPLE, 1/2” NPT X 8” LONG 005557
8 VALVE, GAS, MANUAL SHUT-OFF 1/2” NPT 098458
9 FITTING 90º 1/8” NPT MALE X 1/4” TUBE 097195
10 FRONT PANEL COMPONENTS ASSY 123805
11 PRESSURE GAUGE 2” DIAMETER 156047
12 SIGHT TUBE, 5/8” DIA X 4-3/4” LONG 008742
13 FITTINGS, SIGHT GLASS ASSEMBLY 002845
14 GUARD ROD FOR GAUGE GLASS 002981
15 NUT, HEX #10-24 005470
16 COUPLING, FULL 1/2” NPT 005722
17 NIPPLE, 1/2” NPT X 2-1/2” LG. 005552
18 SWITCH PRESSURE 1/4” NPT 24 PSIG ± 1 108559
19 NIPPLE, 1/4” NPT X 2-1/2” LG 127330
20 ELBOW, 90º 1/4” NPT 005682
21 VALVE, GAS 123815
22 NIPPLE, 1/2” NPT 008877
23 ELBOW 1/2” NPT STREET 004185
24 NIPPLE, 1/2” NPT X 2-1/2” LONG 005552
25 CLAMP, RIGID CONDUIT 3/4” NFPC 127345
26 NUT, HES KEPS 1/4-20 012940
27 UNION, 1/2 NPT - 004186 008504
28 NIPPLE, 1/2” NPT X 1-1/2” LONG 004184
29 ELBOW 008747
32 BOLT, HH, 1/4-20 X 3/4” LONG 005698
33 BRACKET, GAS MANIFOLD 139861
35 BOOT, LOW WATER PROBE 101143
36 STUDWELD, #10-32 X 3/8” 002928
37 NUT, KEPS 10-32 W/SHAKEPROOF WASHER 071256
Key Description Part No.
ELECTRICAL MOUNTING ASSEMBLY 139060
1 ASM., ELECTRICAL PANEL 139187
2 WATER LEVEL CONTROL BOARD 122192
3 PC BOARD MOUNTING POST 099901
4 FUSE BLOCK 077854
5 FUSE 3.0 AMP 077853
6 SCREW #6-32 X 3/8” ROUND HD MACHINE 009697
7 TERMINAL BLOCK 003887
8 SCREW #8-32 X 1-1/4” ROUND HD MACHINE 005056
9 TRANSFORMER 137487
10 SCREW #8-32 X 3/8” HEX HD CAP 069789
11 NUT HEX #10-32 W/SHAKEPROOF WASHER 071256
12 LUG GROUND #14-#16 AWG 129714
13 HARNESS, WIRING (NOT SHOWN) 123864
IGNITION MODULE BOX 127334
1 SPARK IGNITION MODULE ENCLOSURE 123775
2 COVER IGNITION MODULE ENCLOSURE 104948
3 GASKET, COVER 104941
4 SCREW 8-32 X 3/8” LONG 005764
5 IGNITION MODULE 085153
6 NUT, KEPS 6-32 071289
7 CONDUIT, PLASTIC MALE ADAPTER 1/2” NPT 123733
8 CONDUIT NUT, 1/2” 005487
9 SCREW 10-32 X 3/8” LONG 069773
FRONT PANEL COMPONENTS -
1 LABEL INDICATOR LIGHTS & INSTRUCTIONS 170055
2 INDICATOR LIGHT AMBER W/BEZEL 116384
3 INDICATOR LIGHT RED W/BEZEL 116383
4 THERMOSTAT 012313
5 THERMOSTAT ADAPTER (SHAFT BUSHING) 107172
6 SCREW ROUND HEAD 6-32 X 3/8” LONG 009697
7 KNOB, THERMOSTAT 170229
8 TOGGLE SWITCH, SPST, ON-OFF 006904
9 GASKET, LAMP 137434
10 GASKET, SWITCH 137435
11 GASKET, THERMOSTAT 123585
