INSTALLATION AND SERVICE CONNECTIONS
1.0 INSTALLATION INSTRUCTIONS
Set braising pan in place, level appliance using spirit level. Mark hole locations on floor
through anchoring holes provided in flanged adjustable feet.
Remove appliance and drill holes in locations marked on floor and insert proper
anchoring devices.
Re-level the appliance, leveling the unit left to right and front to back.
Bolt and anchor appliance securely to the floor. Seal bolts and flanged feet with Silastic
or equivalent compound.
SERVICE CONNECTIONS
All internal wiring for the skillet is complete.
Make service connections as indicated on page 4.
This must be a waterproof connection from incoming lines.
Ground skillet to terminal provided in control housing. A wiring diagram is provided and
is located inside the control cover panel.
If faucet is provided connect water supply and check for proper operation.
