Hubbardton Forge 844001 - Manual

Installation Instructions
F10
For Rook Robe Hook 84-4001
Hand-Forged, Vermont-Made Lighting and Accessories
P.O. Box 827, 154 Route 30 South, Castleton, Vermont 05735 24241
To Install
Component Parts
A Robe Hook
B Set Screw
C Wall Mount Plate
D Screws
(2)
E Wall Anchors (2)
1. Remove wall mount plate (C) from robe hook (A) by loosening
set screw (B) and sliding wall mount plate (C) from fixture (A)
(Figure 1).
2. Hold wall mount plate (C) in location where robe hook is to be
mounted. With a pencil, mark the location of all mounting holes
in the wall mount plate on the wall behind.
3. If attaching directly to a framing member skip this step. Put the wall
mount plate down and drill 1/4" holes in the locations marked
on the wall if wall anchors (E) are to be
used. For holes using anchors, place the
tapered end of the anchors (E) into the holes
and gently tap them flush to the wall using
a light weight hammer.
4. Install screws (D) through wall mount plate
(C) and into each anchor or directly into a
framing member.
5. Slip robe hook (A) onto wall mount plate
(C) until it is against wall.
6. Align robe hook (A) so it is straight and
tighten set screw (B).
If you need further assistance, or find that you are missing any parts, please contact the dealer from which you purchased
this product. We hope you enjoy your fixture!
* Hubbardton Forge will not be liable for injury or damage caused by improper installation or use of this fixture.
CAUTION: FAILURE TO INSTALL THIS PRODUCT PROPERLY MAY RESULT IN PERSONAL
INJURY OR PROPERTY DAMAGE. We recommend installation by a qualified individual trained in the
building trade.
This product must be installed in accordance with applicable installation code(s), by a person familiar with the
construction and operation of the product and the hazards involved.*
(Figure 1)
(Figure 2)
