English 5
Using The Monitor
Installing / Changing The Batteries
1. Slide the battery cover up to open it.
2. Remove the used batteries and insert new
batteries into the battery compartment as
shown, taking care that the polarities (+)
and (-) are correct.
3. Slide the battery cover down to close it.
Use only R6P, LR6 or AA batteries.
CAUTION
Insert the batteries as shown in the battery compartment. If not, the device will
not work.
When
(LOW BATTERY mark) blinks in the display, replace all batteries with
new ones. Do not mix old and new batteries. It may shorten the battery life, or
cause the device to malfunction.
(LOW BATTERY mark) does not appear when the batteries are drained.
Battery life varies with the ambient temperature and may be shorter at low
temperatures.
Use the specified batteries only. The batteries provided with the device are for
testing monitor performance and may have a limited life.
Remove the batteries if the device is not to be used for a long time.
The batteries may leak and cause a malfunction.
Stored data are cleared when the batteries are removed.
Connecting The Air Hose
Insert the air connector plug into
the air socket firmly.
Selecting The Correct Cuff
Using the correct cuff size is important for an accurate reading. If the cuff is not
the proper size, the reading may yield an incorrect blood pressure value.
The index
and proper fit range, on the cuff, tell you if you are attaching the
correct cuff. (Refer to "Attaching The Arm Cuff" on next page)
If the index
points outside of the range, contact your local dealer for replacement.
Arm Size Recommended Cuff Size Order No.
32 cm to 42 cm Large cuff UA-CUFBLALB
22 cm to 32 cm Medium cuff UA-CUFCAULB, UA-CUFDAULB
18 cm to 22 cm Small cuff UA-CUFBCHLB
Arm size: The circumference of upper arm at the midpoint between the shoulder and elbow.
Step 1
Step 3
Step 2
Air Connector Plug
Air Socket
Air Hose
