Audiovox PRO 9549FT - Manual (Page 7)

RED
87A
85 86
30
CUT
TO
IGNITION
SWITCH
TO
START
SOLENOID
87
TO +12 VDC
IGN./CRANK
EXISTING LOW CURRENT SOLENOID
FEED WIRE (+12VDC, CRANKING ONLY)
ORANGE
OPTIONAL DEVICE or
TRUNK RELEASE
Connect to +12 VDC Battery for
Positive Switched Devices
or
Chassis Ground for Negative
Switched Devices
DARK BLUE
BLACK
SIREN
GREEN w/WHITE
DOME LIGHT
EXISTING
DOOR PIN SWITCH
GREEN w/WHITE
BLACK
(-) TO VEHICLE'S
CHASSIS GROUND
WHITE
+12 VDC BATTERY
Connect to a +12 Volt
Battery Source.
(See Note on Voltage
Sensing)
EXISTING PARKING
LIGHT
DARK BLUE
RED
RED
RED w/
WHITE
5A
FUSE
15A
FUSE
OPTIONAL
SHOCK SENSOR
Red, Black, Green
ENTRY ILLUMINATION
Connect to +12 VDC Battery for
Positive Switched Dome Light
or Chassis Ground for Negative
Switched Dome Light
GROUND SOURCE
Connect to Vehicle's Chassis
Page 7
WHITE w/BLACK
EXISTING TRUNK
RELEASE SWITCH
or
OPTIONAL DEVICE
PRO-9549FT
CONTROL
MODULE
DOOR LOCK
O U T P U T
Blue/White
Y
ellow
Green Orange
White Blue
