3
General
6
• The optional RMU 700 rack mounting kit (3158 Z 00150) al-
lows you to install one or two CU 700 chargers in a 19"
rack.
• Check that the AC mains voltage stated on the included power supply is identical to the
AC mains voltage available where you will use your system. Using the power supply with
a different AC voltage may damage the unit.
• Do not use any power supply other than the AC adapter supplied with the charger.
1. Connect the DC cable of the supplied AC adapter to the 12 V DC jack on the charger rear panel.
2. Connect the AC adapter to a convenient power outlet.
3. The charger is ready to operate. Note that both STATUS LEDs remain dark.
CU
700
12 VDC input for rack-mounted use
12 VDC input
Bottom and Rear
Panels
Optional
Rack Mounting Kit
NOTICE
▲
!
4
Connecting to Power
CU
700
Data interface: RJ11 socket
for connecting the charger to
a computer (via HUB 4000 Q)
