450574-3 www.amdry.com 11
Illus. No. Part No. Qty. Description
1 819096 1 Tumbler Stainless Steel Assembly Complete
for models mfd. as of November 10, 2003
(includes illus. nos. 1 through 3)
819042 1 Tumbler Assembly Complete
for models mfd. prior to November 10, 2003
(includes illus. nos. 1 through 3)
2 319083 4 Perforated Tumbler Stainless Steel Panel
for models mfd. as of November 10, 2003
883328 4 Perforated Tumbler Panel
for models mfd. prior to November 10, 2003
3 150118 40 1/4-20 x 1/4” Phillips Pan Head Screw
* 881619 1 Rotational Sensor Magnet
* Not illustrated.
Tumbler Assembly
