Samsung LTP326WX-XAC - Manual (Page 45)

English- 42
O P E R AT I O N
3
Press the UP/DOWN
buttons to select “Source”,
then press the ENTER
button.
Select a source of the sub
picture by pressing the
UP/DOWN
buttons and
press the ENTER button.
Swapping the Contents of the PIP and Main image
Selecting a Signal Source (External A/V) for PIP
5
Press the UP/DOWN
buttons to select “Ch.(Channel)”,
then press the ENTER
button.
You can select the channel
that you want to view through
sub picture by pressing the
UP/DOWN buttons.
Changing the PIP Channel
6
Press the UP/DOWN
buttons to select “Position”,
then press the ENTER
button.
Changing the Position of the PIP Window
7
Press the UP/DOWN
buttons to select “Size”,
then press the ENTER
button.
Press the EXIT button
to exit.
Changing the Size of the PIP Window
• When the PC is in energy saving mode, you cannot choose the PIP option.
• You may notice that the picture in the PIP window becomes slightly unnatural when you set the main
screen to game or karaoke mode.
• Switch the main screen and the PIP window for normal viewing.
T V
Move Enter Return
PIP : On
Source :
Swap
Size
:
Position :
Ch. :
PIP
TV
AV
S-Video
Component 1
Component 2
4
Press the UP/DOWN
buttons to select “Swap”,
then press the ENTER
button.
Note :If Connector is not connected, Source cannot be selected except TV.
(in both main and sub-screen)
Source selection is possible only when Component 1,
Component 2, HDMI, DVI, or PC is connected.
BN68-00653A-01Eng.qxd 5/7/04 9:04 AM Page 42
