Samsung LS20HANKBHDZS - Manual (Page 45)

Model
General
General
Model Name SyncMaster 923NW
LCD Panel
Size 19 inch(48 cm)
Display area 408.24 mm (H) x 255.15 mm (V)
Pixel Pitch 0.2835mm (H) x 0.2835 mm (V)
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56~75Hz
Display Color
16.7M
Resolution
Optimum resolution 1440 x 900@60Hz
Maximum resolution 1440 x 900@75Hz
Input Signal, Terminated
RGB Analog
0.7 Vp-p ± 5 %
Separate H/V sync, Composite, SOG
TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)
Maximum Pixel Clock
137MHz
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz
Signal Cable
15pin - to - 15pin D-sub cable, Detachable
Dimensions (WxHxD)/ (Without Stand)
439 x 289 x 65.5 mm(Without Stand)
SyncMaster 923NW
