ADP102
Power Output (RMS, 4 ohms):
THD:
Residual Noise:
Xover:
Input Gain Range (MAX - MIN):
Operating Voltage:
Output Efficiency at Full Power:
Protection Circuitry:
Idle Current (no signal):
Standby Current, REM input low:
Size: 50W X 2
<0.05% @10Vrms
120uVrms (A-wtd)
HP/ LP/ FLAT switchable. 50Hz - 500Hz, 12dB/oct.
400mV to >15V
11 - 16V DC (negative ground)
>90%
current (LS output), voltage (+/-), temperature
0.6A
<1mA
229 x 175 x 37mm
Specifications
