Samsung LC24A650XS-ZA - Manual (Page 103)

103
10 Specifications
10
Specifications
10.1 General
The above specifications are subject to change without notice to improve quality.
Model Name C24A650X / C24A650U C27A650X / C27A650U
Panel Size 24 inches (61 cm) 27 inches (68 cm)
Display area 531.36 mm (H) x 298.89 mm (V)
20.9 inches (H) x 11.8 inches (V)
597.6 mm (H) x 336.15 mm (V)
23.5 inches (H) x 13.2 inches (V)
Synchronization Horizontal
Frequency
30~81 kHz
Vertical
Frequency
56~75 Hz
Display Color 16.7M (True 8-bit)
Resolution Optimum
resolution
1920 x 1080 @ 60Hz
Maximum
resolution
1920 x 1080 @ 60Hz
Maximum Pixel Clock 165MHz (Analog,HDMI,USB)
Power Supply This product uses 100 to 240V. Refer to the label at the back of the
product as the standard voltage can vary in different countries.
Signal connectors D-Sub, HDMI, USB UP port
Dimensions (W x H x D) /
Weight (with the stand)
568.0 X 418.0 X 224.5 mm /
5.4 kg
22.4 X 16.5 X 8.8 inches /
11.9 Ib
642.5 X 466.0 X 224.5 mm /
6.3 kg
25.2 X 17.6 X 8.8 inches /
13.9 Ib
Environmental
considerations
Operating Temperature : 50˚F ~ 104˚F(10˚C ~ 40˚C)
Humidity : 10 % ~ 80 %, non-condensing
Storage Temperature : -4˚F ~ 140˚F(-20˚C ~ 60˚C)
Humidity : 5 % ~ 95 %, non-condensing
Plug-and-Play This monitor can be installed and used with any Plug-and-Play
compatible systems. Two-way data exchange between the monitor
and PC system optimizes the monitor settings. Monitor installation
takes place automatically. However, you can customize the
installation settings if desired.
Panel Dots (Pixels) Due to the nature of the manufacturing of this product, approximately
1 pixel per million (1ppm) may appear brighter or darker on the panel.
This does not affect product performance.
