Global OBD II Diagnostics
4 – 12 • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
4 4
PRINT DATA
This function allows you to print the
diagnostic information stored in the
Scan Tool.
The scan tool’s internal battery power
can be used to print data.
Select
Print Data
and press the
ENTER
key. The scan tool informs you
of the printer settings (Custom or
Default), then asks if you wish to
change them.
To change the settings, refer to “
Interface
” on page 3-4 of
Using The
Scan Tool
. Select NO and press the
ENTER
key to begin printing.
If the printout is OK, select YES and
press
ENTER
. Refer to the settings in
the printer manual if the printout is not
OK.
Printing Data (except Playback)
Next, select the data to be printed and
press
ENTER
. The scan tool displays
the menu of those functions that store
data and can be printed.
✓
Make sure the printer is turned on, on-line and connected.
When the selected data does not exist in the scan tool’s memory, a message
informs you to run the function.
If the selected data is stored in the scan
tool, the data automatically transmits to
the printer.
Press
ENTER
to return to the Select
Print Data screen. Either select
another item to print or press
BACK
to
return to the OBDII Function List.
OBDII Function List
|
13)Review Data
]
` 14)Print Data
[
15)Code Lookup
~
Tool Set To Default|
Printer Settings.
Change Settings?
YES
~
Is Printout OK?
NO
~
Select Print Data
` 1)I/M Readiness
2)Read Codes
[
3)Pending Codes
~
Transmitting
To Printer
--Please Wait--
~
All Data Has Been
Sent To Printer
Press ENTER To Cont. ~
