-5-
4. Lapel/Clothes Clip: Attaches headset PTT switch to convenient area.
5. Headset Microphone/Speaker Plug: Connects headset assembly
to SPK/MIC jack on radio.
6. Headset SPK/MIC (CHG) Jack: For use with the supplied Audiovox
headset assembly; accepts headset connector plug (5). Also accepts
wall charger (sold separately) DC input for battery charging.
7. Antenna
8. LCD Display: Displays the current GMRS/FRS channel number as
well as various control function indications.
9. Monitor/FM (MON/FM) Button: Momentarily press to bypass the
squelch and listen to channel activity. Press and hold to access the FM
radio mode.
10. Power Button ( ): Press and hold this button for 2 seconds to
turn the transceiver on or off.
11. VOX HI/LOW/OFF Switch: Enables VOX mode in the HI or LOW
sensitivity position.
12. Down Button ( ): Press this button to decrease the volume or chan-
nel setting.
13. Up Button ( ): Press this button to increase the volume or channel
setting.
14. Call Button (CALL): Momentarily press this button to send a ringing
sound to other radios tuned to the same channel.
15. Channel (CH) Button: Press this button to access the GMRS/FRS
channel select function.Press this button to access the FM radio
search (SE) function when the FM radio mode is active.
