OSD Icon Summary
Icon Function Function Description
Brightness Adjusts display brightness
Contrast Adjusts display contrast
H. Size Increases and decreases screen width
H. Position Shifts display image right or left
V. Size Increase and decrease screen height
V. Position Shifts display image up or down
Pin. Balance Adjusts each side of Pincushion
Pincushion Adjusts concave and convex portion of pincushion effect
Parallelogram Adjusts the tilt of the display sides to the left or right
Trapezoid Adjusts the top and bottom display widths
Rotation Adjusts the rotation of the display clock or anti-clockwise
Color Temp. Adjusts the warmth of the displayed colors
Reset Resets to default values
Degauss Demagnetizes the screen to reduce color impurities
Exit Exits the OSD menu
Specification
Screen Size 17” CRT
Dot Pitch (mm) 0.27
Surface Non –glare
Viewable Image Area 16.14” (41.0 cm)
Input Signal Video Sy nc. RGB Analog 0.7Vp -p/75 Ohm
a. Separate H/V,TTL(+/-)
b. Composite H+V,TTL(+/-)
Scanning Frequency Horizontal (KHz) 30-70
Vertical (Hz) 50-160
Max. Resolution 1280 x 1024
Signal Cable 15-pin mini D-sub
Power Consumption Max. 75 W
Power Supply 100 - 240VAC (W/I CE Mark) 50/60Hz
Power Management Complies with EPA Energy Star ,VESA,
Nutek
Display Modes Preset 6
By User 14
Operating Operating Temperature 0-40°C
Relative Humidity 10-90 %
Dimensions (L x W x H) 419 x 405 x 427 (mm)
Weight Unpacked 14.9 Kgs (32.85 lbs)
