English - 57
Wall- mount adjustment (Sold separately)
Once the wall mount is installed, the position of your TV can be easily adjusted.
Entering the menu
1 Press the ▲, ▼, ◄ or ► button on your remote control.
➢ The Wall-Mount Adjustment screen is displayed.
➢ If the Wall-Mount Adjustment screen is not displayed when clicking on a
direction button while watching your TV, use the menu to display that screen.
• Press the MENU button to display the menu.
Press the ▲ or ▼ button to select Setup, then press the ENTER button.
• Press the ▲ or ▼ button to select Wall-Mount Adjustment, then press the
ENTER button.
Remembering the Position
2 Adjust to the desired position using the ▲, ▼, ◄, ► buttons.
➢ If you press an arrow button when no OSD is displayed on the TV screen, the
Adjustment screen appears.
➢ Press the INFO button to reset. Press the ◄ or ► button to select Yes, then
press the ENTER button. The position is initialized to the default setting.
Press the Blue button.
Press the ▲ and ▼ buttons to select a save mode from either Position 1,
Position 2 or Position in order to save the current position.
➢ To not save the current position, press the RETURN button.
➢ When selecting a save mode, you cannot use the Color buttons.
4 Press the ENTER button to save.
➢ When Position 1 is selected, the message Current position saved as
Position 1 is displayed.
5 Press the ENTER button.
➢ The saved Position appears on the left side of the OSD.
Continued...
TV Rear Panel Auto Wall-Mount
EX-LINK Cable (Not supplied)
Plug & Play ►
Language : English ►
Time ►
Caption ►
Light Effect : Watching TV ►
Wall-mount Adjustment ►
Melody : Off ►
Entertainment : Off ►
Energy Saving : Off ►
AV Color System : Auto ►
PIP ►
Setup T V
Move Return Enter
Wall-Mount Adjustment
Adjust Save Center
►
►
►
►
►
►
►
►
3 2 1 Position
INFO
Save
Return MOVE Enter
Select a mode to Save.
Position 1
Position 2
Position 3
