Installing the stand, Disconnecting the stand – Samsung LNS3252DX-XAA User Manual
Page 59
English-57
Installing the Stand
1. Place the TV faced down on a soft cloth or cushion on a table.
2. Put the stand into the hole at the bottom of the TV.
3. Insert screw into the hole indicated and tighten.
< 2 >
< 3 >
Disconnecting the Stand
1. Place the TV faced down on a soft cloth or cushion on a table.
2. Remove four screws from the back of the TV.
3. Separate the stand from the TV.
4. Cover the bottom hole with a cap.
< 2 >
< 3 >
< 4 >
Stand Swivel Function
(LN-S3251D/LN-S3252D/LN-S4051D/LN-S4052D)
Place the TV more than 7.87 inches(200 mm) away from the wall.
There should be enough space between the wall and the TV.
Place the TV on a flat and stable space to easily swivel the TV.
-20˚ ~ 20˚
The TV can be swiveled to the left or right.
• You can adjust the angle up to 20
°
to the left or right.
BN68-00998A-03Eng.qxd 6/28/06 7:32 PM Page 57
